Honeywell V8295A1016 Gas Valve Module – Trusted Solenoid Control Solution
- Pipe Size (inch): 1/2 in.
- Pipe Size (DN): DN15
- Capacity (cfh): 250 cfh
- Capacity (m3/hr): 7.1 m3/hr
- Voltage: 24 Vac
- Approximate, Dimensions: 4 7/16 in. high x 2 7/8 in. wide x 2 3/16 deep
(113 mm high x 73 mm wide x 56 mm deep) - Current Ratings: 0.8 max amps at rated Vac/Hz
- Pressure Ratings (psi): 2 psi
- Pressure Ratings (kPa): 13.8 kPa
- Approvals, Underwriters Laboratories Inc.: Component Recognized; File No. YLOZ
- Approvals, CSA: Certificate No. 158158- 1154280, Guide No. C3371-03, 83
Original price was: $367.00.$319.00Current price is: $319.00.
(Save $48.00)
In stock
V4295; V8295 Solenoid Gas Valves
V4295A/V8295A normally closed and V4295S/V8295S normally
open (vent) solenoid gas valves, are suitable for furnaces, ovens,
atmospheric burners, commercial water heaters, rooftop make-up
air units, power burners, and commercial/industrial boilers.
Description
V4295A/V8295A normally closed and V4295S/V8295S normally
open (vent) solenoid gas valves, are suitable for furnaces, ovens,
atmospheric burners, commercial water heaters, rooftop make-up
air units, power burners, and commercial/industrial boilers.
• V8295A, S are used with 24 Vac controllers.
• V4295A, S are used with 120 Vac controllers.
• Positive close off of gas flow when de-energized.
• High valve spring force allows up to 0.7 psi back pressure at valve
seat.
• No inlet pressure influence at valve seat.
• Inlet pressure changes do not affect ability to close valve.
• Low operating noise.
• Low rush-in current.
• Upstream and downstream taps allows tapping and testing pressure
points.
Specifications
- Type of FuelAir; natural; manufactured; mixed; LP
- Pressure TappingInlet and outlet pressure taps – 1/4 in. NPT
- Body PatternStraight-through, non-offset
- Valve Opening Timeless than 1 sec
- Valve Closing Timeless than 1 sec
- MountingVertical to 90 degrees from vertical
- MaterialsBody – Die-cast aluminum
- Frequency50 Hz; 60 Hz
- Electrical ConnectionsScrew terminals
- Operating Temperature Range-40°F to +140°F (-40°C to +60°C)
- Approvals, Swiss REAcceptable
- Approvals, Control Safety DevicesAcceptable
Additional information
| Dimensions | 11.3 × 7.3 × 5.6 cm |
|---|
