Honeywell Module- P532AC channel Industrial Flame Monitoring Signal Processors

The P532/P531 supports three separate viewing heads, two
S55XBE and one S70X. Independent 2 x SPDT Flame On relay
contacts are provided for each viewing head (6 total). 0-20 or
4-20mA scalable analog output also provided for each viewing
head. SIL 3 capable.
• 3 channels.
• Two SPDT flame relay outputs, one SPDT self-check relay output
and one N.O. alarm relay output per channel.
• FM and CSA approved.
• Monitor the UV and IR flame component simultaneously or
separately when using the S550BE viewing head .
• Monitor 3 viewing heads simultaneously.
• Independent configuration for each viewing head.
• 2 sets of configuration data per viewing head.
• Viewing head temperature indication.
• Automatic set-up functionality.
• Automatic viewing head detection.
• Modbus and RS422 protocol compatible.
• NEMA 1 Enclosure Rated.
