Honeywell Valve Module- V8046C1022/U Pilot Gas Valve Control
- Pipe Size (inch): 1/4 in.
- Capacity (cfh): 55 cfh
- Capacity (m3/hr): 1.56 m3/hr
- Voltage: 24 Vac
- Frequency: 60 Hz
- Electrical Connections: Two 36-in. leadwires and 1/2 in. conduit bushing
Honeywell Vaporstat® Module- L408J1017/U | Pressure and Limit Controllers
- Operating Range (psi): 0 to 4 psi
- Operating Range (kPa): 0 to 28 kPa
- Differential Pressure Range (psi): 2 to 16 oz/in2
- Differential Pressure Range (kPa): 0.9 to 6.9 kPa
- Switch Operation: Auto recycle
- Switching Action: SPDT make R-W, break R-B on pressure rise
Honeywell Vaporstat® Reliable Module- L408J1025/U Pressure and Limit Controllers
- Operating Range (psi): 0 to 16 oz/in2
- Operating Range (kPa): 0 to 6.9 kPa
- Differential Pressure Range (psi): 2 to 16 oz/in2
- Differential Pressure Range (kPa): 0.9 to 6.9 kPa
- Switch Operation: Auto recycle
- Switching Action: SPDT make on pressure rise Only
- Comments: Miss-wiring Compliant
Honeywell Vaporstat® Reliable Module- L408J1033/U Pressure and Limit Controllers
- Operating Range (psi): 0 to 4 psi
- Operating Range (kPa): 0 to 28 kPa
- Differential Pressure Range (psi): 2 to 16 oz/in2
- Differential Pressure Range (kPa): 0.9 to 6.9 kPa
- Switch Operation: Auto recycle
- Switching Action: SPDT make on pressure rise Only
- Comments: Miss-wiring Compliant
Honeywell Venturi Mixing Unit- VMU300A1046 Control Module
- Body Pattern: Straight flange
- Maximum Safe Operating Pressure (psi): 1/2 psi (CSA approved)
- Maximum Operating Pressure (mbar): 35 mbar (CSA approved)
- Reference Load: 300 kW (1,024,000 Btuh)
Honeywell Venturi Mixing Unit- VMU335A1018 Control Module
- Body Pattern: Straight flange
- Maximum Safe Operating Pressure (psi): 1/2 psi (CSA approved)
- Maximum Operating Pressure (mbar): 35 mbar (CSA approved)
- Reference Load: 335 kW (1,143,000 Btuh)
Honeywell- C6097B3101/U Pressure Safety Switch Reliable Control Module
- Adjusting range * in WC (mbar): 40 - 200 in. wc 100 - 500 mbar
- Mean switching differential at min. and max. setting: 3.2 - 6.8 in. wc 8 - 17 mbar
- Differential type: Subtractive
- Switch Operation: Auto Recycle
- Switch Action at Setpoint: Breaks NC to COM on pressure rise.
Honeywell- C7061A1053/U Module Dynamic Self-Check Ultraviolet Flame Detector
- NEMA Rating: NEMA 4
- Lead Length: 96 in. (2438 mm)
- Electrical Connections: Color-coded leadwires
- Mounting: 1 in. NPT
- Electrical Ratings: 120 Vac
- Frequency: 55 Hz; 60 Hz
- Ambient Temperature Range: -40°F to +175°F (-40°C to +79°C)
Honeywell- L4079B1058/U Pressuretrol® Pressure and Limit Control Device
- Application: Provide limit control of steam, air, non-combustible gases or non-corrosive fluids
- Operating Range (psi): 5 to 50 psi; 85 psi - Maximum Sustained
- Operating Range (kPa): 35 to 350 kPa; 586 kPa - Maximum Sustained
- Switch Operation: Manual Reset
- Switching Action: SPST break on pressure rise
Honeywell- Module ET401A1/B Efficient Ignition Transformers
- Application: Gas Ignition Transformer, Bulk
- Voltage: 110 – 120 Vac
- Frequency: 50/60 Hz
Honeywell- Module Q624A1014/U Solid State Ignition Transformers
- Application: Gas Ignition Transformer
- Voltage: 120 Vac
- Frequency: 50 Hz; 60 Hz
Honeywell- Safety Module V48A2151/U Diaphragm Gas Valves
- Pipe Size (inch): 3/4 in.
- Pipe Size (DN): DN20
- Pilot Tapping: 1/8-27 NPT
- Voltage: 120 Vac
- Approximate, Dimensions: 5 7/16 in. high x 3 13/16 in. wide x 4 5/8 in. deep (138 mm high x 97 mm wide x 118 mm deep)
- Pressure Rating (psi): 1/2 psi
- Pressure Rating (kPa): 3.4 kPa
- Current Ratings: 0.13 max amps at rated Vac/Hz
- Includes: Ground terminal
Honeywell- V4295A1023 Solenoid Gas Valve Control Module
- Pipe Size (inch): 3/4 in.
- Pipe Size (DN): DN20
- Capacity (cfh): 645 cfh
- Capacity (m3/hr): 18.3 m3/hr
- Voltage: 120 Vac
- Approximate, Dimensions: 5 1/4 in. high x 3 7/16 in. wide x 2 3/4 in. deep (133 mm high x 87 mm wide x 70 mm deep)
- Current Ratings: 0.16 max amps at rated Vac/Hz
- Pressure Ratings (psi): 2 psi
- Pressure Ratings (kPa): 13.8 kPa
- Approvals, Underwriters Laboratories Inc.: Listed: File No. MH18476, V1, S1 - Guide No. YIOZ
- Approvals, CSA: Certificate No. 158158- 1154280, Guide No. C3371-03, 04, 83
Honeywell- V8944C1017/U Diaphragm Gas Valves Two Stage Pressure Regulating
- Type of Fuel: LP
- Pipe Size (inch): 1 in
- Pipe Size (DN): DN25
- Opening Characteristics: Slow Opening 2-stage
- Valve Opening Time: 3 to 25 sec
- Pressure Regulator Setpoint (in. wc): Adj. Range, Low Fire – 1.4 in. wc to 4.2 in. wc; Adj. Range, High Fire – 8.8 in. wc to 11.5 in. wc; Factory Setting, Low Fire – 1.4 in. wc; Factory Setting, High Fire – 10.0 in. wc
- Comments: (3) 30" leadwires
